= OPTICAL FIBER FIRE RESCUE LIGHTING LINE = In environments with low visibility such as fire and smoke, the luminous wire used t o guide the escaperoute, which consists of a power supply system, a luminous line body, and a winding turntable. «Main Features« - Optical fiber transmission - - Photoelectric separation technology - - Free surface accurate light distribution - - Uncharged light cable, can be used underwater - - Continuous luminous brightness not less than 10cd/m2 - - Choice of length: 50m / 100m / 200m / 300m / 500m - - Type of system: Conventional / Explosion Proof / Communication / Portable (Customised) - «Light Line Structure« «Application Scenarios« = BUILDING RESCUE = = UNDERGROUND PASSAGE RESCUE = = UNDERWATER RESCUE = «Specification« Size 305 x 215 x 406mm (conventional 100m / 200m / 300m type) 293 x 214 x 400mm (explosion proof 100m / 200m type) 200 x 200 x 100mm (portable 50m type, by customization only) Line Diameter 3.5mm (conventional type) 4.6mm (communiction type) Weight 4.5kg±2% (conventional 100m type) 5.6kg±2% (explosion proof 100m type) >2kg (portable 50m type) Luminous Material SiO2 Line Material Quartz fiber, Steel wire rope, Plastic PVC Line Length 50m / 100m / 200m / 300m / 500m Continuous operationg hours >14 hours (constant-on)>28 hours (flash) Photoelectric conversion efficency 30~35% Battery Type Rechargable Li-ion Battery Battery Capacity 10.4Ah Operating voltage Input DV12V, 0V Line working current 0V Flashing Frequency 1.5Hz Tensile Strength >1100N (metal wire only) Compressive Strength Pass Waterproofness IP66 (conventional type) IP67 (explosion proof type) Max surface temperature No temperature rise (same as environmental temperature) Certification GB 26783-2011 Ex ic op is IIC T4 Gc (explosion proof type only) Ex op is tc IIIC T130℃ Dc (explosion proof type only)
